● Product Overview

Belt feeder is the most commonly used feeding equipment. According to the requirements of the conveying process, it can be conveyed by a single machine, multiple machines, or combined with other conveying equipment to form a horizontal or inclined conveying system to meet the needs of different layout types of work lines.

【 Applicable Materials 】 It can be used to transport various bulk and granular materials with a stacking density of 0.5~2.5t/

【 Scope of Application 】 Widely used in metallurgy, mineral processing, building materials, hydropower and other departments

Production capacity: 10-450t/h

● Working principle of the product

The material is fed onto the surface of the belt conveyor through the feeding funnel. With the rotation of the AC speed regulating motor, the belt slowly moves forward, and the material on the surface is fed into the next process through the first round, achieving continuous feeding. There are two ways to adjust production capacity: one is to adjust the speed of the AC speed regulating motor, and the other is to adjust the insertion depth of the regulating gate installed on the feeding hopper.

● Product advantages

1. Low power consumption and easy operation;

2. Easy installation and large conveying capacity;

3. Low noise

● Product parameters
