This machine is designed with comprehensive reference to the characteristics of the Finnish Ottokunp OK flotation machine and the American Doyle Oliver flotation machine

▲ Structural characteristics

The spindle part is mounted on the frame, with a lightweight structure and easy installation

The impeller is conical in shape, and the stator is radial, with strong stirring ability and low power consumption

Adopting a U-shaped groove, with less sedimentation of tailings

Small impeller diameter, low circumferential speed, and low power consumption

▲ Performance characteristics

◇ Low power consumption, can save 30-50% energy

◇ Good air dispersion, uniform bubble dispersion and stable foam

Solid particles can be fully suspended, not easily settled in the tank, with good mixing of slurry and gas, and high flotation indicators

◇ Fragile parts have light wear and long service life

▲ Special Reminder

※ Mechanical mixing type; Cannot self inhale; Cannot self absorb mineral slurry; The homework room needs to be configured with stairs (with a drop of 300-400mm)

※ Can form a combined flotation unit with JYF (Jinye Floating) flotation machine, serving as a direct current tank
