▲ Structural characteristics

The impeller is equipped with backward tilting double-sided blades, which can achieve dual circulation of slurry in the tank

The gap between the impeller and the cover plate is large, resulting in a large suction volume

Low circumferential speed of impeller, long service life of vulnerable parts

● Forward inclined tank, small dead angle, fast foam movement

▲ Performance characteristics

◇ High air intake and low energy consumption

◇ Long lifespan of vulnerable parts

◇ Beneficial for the flotation of coarse-grained minerals

▲ Special Reminder

Mechanical mixing; Self inhalation; Self-priming slurry

※ It can form a combined flotation unit with JJF flotation machine, serving as the suction tank for each operation
