▲ Structural characteristics

Shallow groove type, small impeller diameter, low speed, low power consumption

The clearance between the impeller and the stator is large, and the stator is a cylinder with elliptical holes, which is conducive to the mixing and dispersion of air and slurry

The height of the stator is lower than that of the impeller, and the circulation volume of the slurry is large, up to 2.5 times

● The umbrella shaped perforated dispersion cover of the stator can separate the vortex generated by the impeller from the foam layer, so as to keep the pulp surface stable

▲ Performance characteristics

The circulation volume of the slurry is large, up to 2.5 times, which is beneficial for the mineralization of minerals, pharmaceuticals, and gases

◇ Large suction capacity and good dispersion effect

Moderate mixing degree, good suspension of solid particles, no settling in the tank, no need to discharge ore when parking

◇ Wide range of particle size that can be processed, high recovery rate in mineral processing

▲ Special Reminder

Mechanical mixing; Self inhalation; Cannot self absorb mineral slurry; The homework room needs to be configured with stairs (with a drop of 300-400mm)

● Can form a combined flotation unit with SF type flotation machine, with SF type as the suction tank and JJF type as the DC tank
