Product Overview

A medium and fine crushing equipment, the spring is both a safety device and affects the crushing force. The form of the crushing chamber is determined by the purpose of the ore: the standard type is suitable for medium crushing; Medium size suitable for medium to fine crushing; Short head cone crusher is suitable for fine crushing.

Production capacity: 1-500t/h

【 Scope of application 】 Medium to high hardness ores and rocks, such as iron ore, copper ore, limestone, granite, quartz, etc

【 Maximum particle size 】 300mm

● Product Structure

The structure of a cone crusher mainly consists of a frame, a horizontal shaft, a moving cone, a balance wheel, an eccentric sleeve, an upper crushing wall (fixed cone), a lower crushing wall (moving cone), a hydraulic coupling, a lubrication system, a hydraulic system, and a control system.

● Working principle of the product

During the operation of the cone crusher, the electric motor drives the eccentric sleeve to rotate through the transmission device. The moving cone rotates and swings under the pressure of the eccentric sleeve. The section of the moving cone near the static cone becomes the crushing chamber, and the material is crushed by multiple compressions and impacts from the moving cone and static cone. When the moving cone leaves the section, the material that has been crushed to the required particle size falls under its own gravity and is discharged from the bottom of the cone.

● Product advantages

1. The moving cone rotates continuously, and the material crushing and unloading processes alternate continuously along the working surface, resulting in high productivity;

2.     . The material is sandwiched between two cones and subjected to compression, bending, and shearing, making it easy to break and consuming less power;

3. The product has a relatively uniform material quality and a cubic shape, and the wear on the working surface of the moving cone is also relatively uniform;

4. Both the moving cone and the fixed cone are positioned upright. When the moving cone swings, there is a parallel band with equal gap between the moving cone and the fixed cone near the discharge port of the crushing chamber, making the finished material uniform. The feeding port size is not large and can handle materials that have undergone initial crushing;

5. This series of cone crushers adopts two sealing methods, dry oil or water, to prevent dust and impurities from entering the body, thereby ensuring the cleanliness of lubricating oil, extending the service life of sliding bearings and thrust ball bearings, and making the machine operate reliably.
