[Introduction]: Adsorption Filter Filtration is a means of removing suspended solids from water. However, for oily wastewater, general
Filtration is a means of removing suspended solids from water, but general filtration processes have little effect on oily wastewater. The adsorption filter produced by our company is a new type of filtration equipment developed for the treatment of oily wastewater and heavy metal ions. It has played a huge role in sewage treatment projects in various industries;
This product uses specially processed walnut shells, activated carbon, and other materials as filtration media, which have strong adsorption capacity. The filter material can be backwashed and regenerated, with strong compressive strength (23.4kgf/cm2), stable chemical properties (not easily dissolved in acid or alkali solutions), high hardness, good wear resistance, and long-term use without replacement. It has strong adsorption and interception ability (25% -53%), good hydrophilicity, and oil immersion resistance. According to water quality requirements, single-stage or two-stage series connection can be used.
Technical parameter table
| 处理能力(m3/h) | 直径(mm) | 过滤面积(m2) | 配套水泵 | 功率(kw) | ||
型号 | 扬程(m) | 功率(kw) | |||||
BXXG-800 | 10 | 800 | 0.5 | IS50-32-200A | 35 | 4 | |
BXXG-1000 | 20 | 1000 | 0.785 | IS65-40-200A | 38 | 5.5 | 4 |
BXXG-1200 | 30 | 1200 | 1.13 | IS80-65-160A | 35 | 7.5 | |
BXXG-1600 | 50 | 1600 | 2.01 | IS80-50-200 | 45 | 15 | 5.5 |
BXXG-2000 | 80 | 2000 | 3.14 | IS100-65-200A | 38 | 18.5 | 11 |
BXXG-2400 | 110 | 2400 | 4.52 | IS100-65-200 | 45 | 22 | 20 |
BXXG-2600 | 130 | 2600 | 5.306 | IS150-125-400A | 38 | 37 | 22 |
BXXG-2800 | 150 | 2800 | 6.154 | IS150-125-400A | 38 | 37 | 30 |
BXXG-3000 | 160 | 3000 | 7.065 | IS150-125-315 | 32 | 37 | 30 |
