▲ High temperature, high pressure, cyanide free, automatic desorption control, with high efficiency, low consumption, and fast characteristics

▲ Efficient: When the gold loaded carbon grade reaches 3000g/t, the desorption rate can reach over 96%, and the lean carbon grade can be reduced by 50% to 75% compared to conventional desorption electrolysis devices

▲ Fast: The desorption electrolysis temperature can reach up to 1500C (30-550C higher than other models), and the system working pressure can reach up to 0.5Mpa (higher than other models)

▲ Generally, it is 0.2-0.5Mpa high, so the desorption electrolysis time is very fast, usually 12 hours, which is reduced by 50% to 75%

Low consumption: The desorption electrolysis temperature is the same, no heat exchange is required, and due to its fast operation, the total power consumption is 1/2-1/4 of that of conventional systems

● Cyanide free: No need to add sodium cyanide in the desorption solution, low cost, and no pollution

High grade gold mud, no need for reverse electrolysis, easy extraction of gold mud

● Automatic control; Specially equipped with liquid level control system, temperature control system, and automatic control system

● Safety: Equipped with triple safety protection measures, namely system intelligence, automatic pressure limiting and release mechanism, and safety valve
